| Ethernet |
| Standards |
IEEE802.3bt Power over Ethernet |
| Processing Type |
Forward |
| Half-duplex, Full duplex |
| Forward Filter Rate |
1,488,000pps (1000Mbps) |
| Cabling |
1000Base-TX: Cat5 or above |
| Maximum Distance |
Cat5 UTP up to 100m |
| Connector |
2 x RJ45 |
| Electrical and Mechanical |
| Input Power |
48~57VDC (Terminal Block) |
| Power Consumption |
95W Max. |
| LED Indicators |
| Power |
Power Status |
| PoE |
PoE Status |
| PoE |
IEEE802.3bt, up to 90W |
| 4 pair output power for PoE++ (90W) |
| 2 pair output power for PoE+ (30W) |
| Dimensions |
96 × 80 × 31 mm |
| Weight |
0.2 Kg |
| Casing |
Aluminum Case |
| Mounting options |
Din Rail / Wall Mount |
| Environmental |
| Operation Temperature |
-40˚C to 75˚C (-40˚F to 167˚F) |
| Storage Temperatur |
-40˚C to 85˚C (-40˚F to 185˚F) |
| Relative Humidity |
5% to 95% non-condensing |
| MTBF |
> 200,000 hrs |
| Regulatory Approvals |
| ISO9001, CE, FCC, RoHS |
| EMI: |
| EN55022:2010+AC: 2011, Class A |
| EN 61000-3-2: 2006+A1: 2009+A2: 2009 |
| EN 61000-3-3: 2013 |
| EN55024:2010 |
| EMS: |
| IEC 61000-4-2: 2008 (ESD) |
| IEC 61000-4-3: 2010 (RS) |
| IEC 61000-4-4: 2012 (EFT) |
| IEC 61000-4-5: 2014 (Surge) |
| IEC 61000-4-6: 2013 (CS) |
| IEC 61000-4-8: 2009 (PFMF) |
